| 模组 |
SIM8200EA-M2 |
SIM8202G-M2 |
FM650-CN |
RM520N-GL |
| 工作频段 |
|
| Sub-6G |
SA: n1, n2, n3, n5, n7, n8, n12, n20, n28, n38, n40, n41, n48, n66, n71, n77, n78, n79（n79 是 SIM8202G-M2 独有） |
n1, n2, n3, n5, n28, n41, n77, n78, n79 |
n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29, n30, n38, n40, n41, n48, n66, n70, n71, n75, n76, n77, n78, n79 |
| NSA: n41, n77, n78, n79（n79 是 SIM8202G-M2 独有） |
| LTE-FDD |
B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B29, B30, B32, B66, B71 |
B1, B3, B5, B8 |
B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B29, B30, B32, B66, B71 |
| LTE-TDD |
B34, B38, B39, B40, B41, B42, B43, B48 |
B34, B38, B39, B40, B41 |
B34, B38, B39, B40, B41, B42, B43, B48 |
| WCDMA |
B1, B2, B3, B4, B5, B8 |
B1, B5, B8 |
B1, B2, B4, B5, B8, B19 |
| GNSS |
GPS，GLONASS，北斗，伽利略和 QZSS |
- |
GPS，GLONASS，北斗，伽利略和 QZSS |
| 数据传输 |
|
| Sub-6G |
2.4Gbps (DL) / 500Mbps (UL) |
1.92Gbps (DL) / 630Mbps (UL) |
SA：2.4Gbps (DL) / 900Mbps (UL)
NSA：3.4Gbps (DL) / 550Mbps (UL) |
| LTE |
1Gbps (DL) / 200Mbps (UL) |
487Mbps(DL) / 150Mbps(UL) |
1.6Gbps(DL) / 200Mbps(UL) |
| HSPA+ |
42Mbps (DL) / 5.76Mbps (UL) |
| 硬件说明 |
|
| SIM卡 |
1.8V/3.0V |
| 供电电压 |
5V 3A |
| 天线接口 |
6 天线 (IPEX-4 接口) |
4 天线 (IPEX-4 接口) |
| 模组尺寸 |
52.0×30.0×2.3mm |
42.0×30.0×2.3mm |
52.0×30.0×2.3mm |
| 应用场景 |
|
| 适用地区 |
除美洲以外的覆盖了 5G Sub-6G 频段的国家或地区 |
中国 |
全球 |
| 典型应用 |
CPE/智能网关/无人机/视频直播/远程医疗/智能安防 |
